Juggernaut Classic Duo Step-Thru Sale

Sale price CA$3,299.00 Regular priceCA$4,499.00
Save CA$1,200

Delivers the sweet spot for capability and comfort with a mid-drive motor

We are sorry, but this product is currently sold out!

However, if you are still interested, please fill the form below and we will notify you when we are back in stock.

Sale price CA$3,299.00 Regular priceCA$4,499.00
Lifetime Support
14 Days Return
Custom Built
customer-service-img
Want to see the bike live?

Book a live showroom demonstration and see the bike live today!

60+

Miles Range

120Nm

Torque For Extreme Hills

52V 17Ah

Strong, Reliable Battery

The Duo Series. Ebikes For Everyone.

The Juggernaut Duo Series is all about flexibility. Hub-drive or mid-drive, step-over or step-thru, single battery or dual battery, entry-level or high-end. No matter your needs, there's probably a Duo for you.

Watch this video to see how The 3 Duo models stack up.

The Next Step In Performance.

Looking for a little more power, but don't want to break the bank? Meet The Classic Duo. With a 750W mid-drive motor, The Classic delivers a considerable performance boost without sacrificing affordability. Use the bikes gears to your advantage and tackle tough terrain with ease. Your adventure awaits.

All The Good Stuff, And More.

Technical Specifications

Frame
6061 aluminum
Front hub
135mm 36h
Seat post
27.2mm
Fork
Mozo, 80mm travel, 135mm dropout, preload and mechanical lockout (16.5" step-thru)/rst guide, 80mm travel (18.5" step-thru)
Front axle
5mm qr
Seat post clamp
Qr
Headset
Threadless 1-1/8 1-1/2 tapered
Rear hub
170mm 36h
Motor
750w bbs02 mid-drive
Shifter rear
Shimano alivo 9 speed trigger shifter
Rear axle
5mm qr
Rear derailleur
Shimano alivo 9 speed
Rims
Black 36h
Display
C961
Cassette
Shimano 12-36t
Tire sizes
24x4" (16.5" step-thru)/26x4" (18.5" step-thru)
Lights
Integrated headlight, integrated taillight
Chain
Kmc x9
Handlebar
31.8mm clamp, 700mm wide, 80mm rise
Assist type
Cadence
Crank set
170mm arms 44t chainring
Stem
Promax 90mm
Assist levels
0-5 (0-2, 0-9)
Bottom bracket
Bafang square taper
Grips
Slide on
Throttle
Thumb throttle
Brakes
Logan dual piston hydraulic w/180mm rotors (16.5" step-thru)/tektro e350 dual piston hydraulic w/160mm rotors (18.5" step-thru)
Saddle
Wide saddle
Other
Front and rear fenders, rear rack, kickstand (16.5" step-thru)/front and rear fenders, rear rack, kickstand (18.5" step-thru)
Brake levers
Logan adjustable w/motor cut-offs (16.5" step-thru)/tektro adjustable w/ motor cut-offs (18.5" step-thru)
Frame
6061 aluminum
Front hub
135mm 36h
Seat post
27.2mm
Fork
Mozo, 80mm travel, 135mm dropout, preload and mechanical lockout (16.5" step-thru)/rst guide, 80mm travel (18.5" step-thru)
Front axle
5mm qr
Seat post clamp
Qr
Headset
Threadless 1-1/8 1-1/2 tapered
Rear hub
170mm 36h
Motor
750w bbs02 mid-drive
Shifter rear
Shimano alivo 9 speed trigger shifter
Rear axle
5mm qr
Rear derailleur
Shimano alivo 9 speed
Rims
Black 36h
Display
C961
Cassette
Shimano 12-36t
Tire sizes
24x4" (16.5" step-thru)/26x4" (18.5" step-thru)
Lights
Integrated headlight, integrated taillight
Chain
Kmc x9
Handlebar
31.8mm clamp, 700mm wide, 80mm rise
Assist type
Cadence
Crank set
170mm arms 44t chainring
Stem
Promax 90mm
Assist levels
0-5 (0-2, 0-9)
Bottom bracket
Bafang square taper
Grips
Slide on
Throttle
Thumb throttle
Brakes
Logan dual piston hydraulic w/180mm rotors (16.5" step-thru)/tektro e350 dual piston hydraulic w/160mm rotors (18.5" step-thru)
Saddle
Wide saddle
Other
Front and rear fenders, rear rack, kickstand (16.5" step-thru)/front and rear fenders, rear rack, kickstand (18.5" step-thru)
Brake levers
Logan adjustable w/motor cut-offs (16.5" step-thru)/tektro adjustable w/ motor cut-offs (18.5" step-thru)
Frame
6061 aluminum
Front hub
135mm 36h
Seat post
27.2mm
Fork
Mozo, 80mm travel, 135mm dropout, preload and mechanical lockout (16.5" step-thru)/rst guide, 80mm travel (18.5" step-thru)
Front axle
5mm qr
Seat post clamp
Qr
Headset
Threadless 1-1/8 1-1/2 tapered
Rear hub
170mm 36h
Motor
750w bbs02 mid-drive
Shifter rear
Shimano alivo 9 speed trigger shifter
Rear axle
5mm qr
Rear derailleur
Shimano alivo 9 speed
Rims
Black 36h
Display
C961
Cassette
Shimano 12-36t
Tire sizes
24x4" (16.5" step-thru)/26x4" (18.5" step-thru)
Lights
Integrated headlight, integrated taillight
Chain
Kmc x9
Handlebar
31.8mm clamp, 700mm wide, 80mm rise
Assist type
Cadence
Crank set
170mm arms 44t chainring
Stem
Promax 90mm
Assist levels
0-5 (0-2, 0-9)
Bottom bracket
Bafang square taper
Grips
Slide on
Throttle
Thumb throttle
Brakes
Logan dual piston hydraulic w/180mm rotors (16.5" step-thru)/tektro e350 dual piston hydraulic w/160mm rotors (18.5" step-thru)
Saddle
Wide saddle
Other
Front and rear fenders, rear rack, kickstand (16.5" step-thru)/front and rear fenders, rear rack, kickstand (18.5" step-thru)
Brake levers
Logan adjustable w/motor cut-offs (16.5" step-thru)/tektro adjustable w/ motor cut-offs (18.5" step-thru)

Size & Fittings

1
Effective Top Tube Length
620mm 24.4in
2
Seat Tube Length (Classic Bike Size)
420mm 16.5in
3
Reach
460mm 18.1in
4
Stack
660mm 26in
5
Chainstay Length
520mm 20.5in
6
Standover Height
400mm 15.7in
7
Head Angle
68° -
8
Seat Angle
71° -
9
Head Tube Length
135 mm 5.3 in
10
Fork Length
500mm 19.7in
11
Front Center
720mm 28.3in
12
BB (Bottom Bracket) Drop
60mm 2.4in
13
Fork Offset
35mm 1.4in
14
Wheelbase
1230mm 48.4in
15
Total Length
1980mm 78in
16
Max Seat Height
950mm 37.4in
17
Min Seat Height
770mm 30.3in
18
Handlebar Height
1090mm 42.9in
19
Weight (Without Battery)
31.4kg 69.2lb
1
Effective Top Tube Length
680mm 26.8in
2
Seat Tube Length (Classic Bike Size)
470mm 18.5in
3
Reach
510mm 20.1in
4
Stack
600mm 23.6in
5
Chainstay Length
520mm 20.5in
6
Standover Height
420mm 16.5in
7
Head Angle
68° -
8
Seat Angle
71° -
9
Head Tube Length
135 mm 5.3 in
10
Fork Length
520mm 20.5in
11
Front Center
760mm 29.9in
12
BB (Bottom Bracket) Drop
60mm 2.4in
13
Fork Offset
35mm 1.4in
14
Wheelbase
1280mm 50.4in
15
Total Length
2000mm 78.7in
16
Max Seat Height
1010mm 39.8in
17
Min Seat Height
840mm 33.1in
18
Handlebar Height
1140mm 44.9in
19
Weight (Without Battery)
32.5kg 71.7lb
