Juggernaut XD Duo ST

Sale price CA$6,999
Satin Black
Packages
Battery
Range Extender


Add an additional battery to extend your bikes range and give you that boost!

**This option adds an extra battery that mounts on top of the frame that doubles the range of the stock battery.
Upgrades
Brakes


Enhance your safety and control on every ride by upgrading your eBike brakes.

Fork


Elevate your ride's comfort and control by upgrading your ebike fork, ensuring a smoother journey over any terrain.

**The Upgraded Fork options are incompatible with the front fender included with the bike.
Drive Train


Unmatched power, smooth performance, and eco-friendly commuting in one seamless package.

**Drivetrain upgrade included Shifter, Cassette, Derailleur and Chain
Biktrix A-Bars


The swept-back design provides an upright riding position with multiple comfortable hand positions so you can enjoy further and more frequent rides!

Throttle


Select a Thumb Throttle or Twist Throttle for your eBike

**Right-Hand Twist throttle is incompatible with A-Bar Upgrade
Seatpost


Suspension seatposts offer great riding comfort as they absorb many of the imperfections on the road/trail.

***Adding a suspension seatpost to your eBike will increase the minimum seatpost height by 75mm/3" to 150mm/6"
Accessories
Canvas Pannier Bags
Canvas Pannier Bags


These Canvas bags offer great convenience and carrying capacity!

Coloured Pedals


Add some extra flair to your eBike with a set of coloured pedals!

Warranty

Secure your investment by opting for an extended warranty through the BiktrixCare+ plan.

Sale price CA$6,999.00
Shipping: Leaves within 4-6 Weeks
2300W Mid-Drive

Motor Power

52V 17Ah 910Wh

est. 65km Range

+5'6"ft / 330lb

Max Load

Torque Sensor

Powerful Pedal Assist

25+ Point Quality

Control Checklist

65+

Kilometers Range

2300W

Mid-Drive

52V 17Ah

Strong, Reliable Battery

Unmatched. Power. Reliable.

Getting plenty of power to the rear wheel is exciting, but has always come at the risk of ongoing costs in replacement parts, and time lost riding. Many casual to moderate riders will not ride hard enough to cause such issues. But for those who want to push the limits, a more robust solution was needed to build the dream e-bike machine, with extreme endurance.

Designed And Built In Canada

The XD Drive system was developed in Saskatoon, Canada, by a team of e-bike enthusiasts with a shared passion for better solutions to transportation. The global pandemic conditions forced them to improvise, adapt, and overcome, tackling the bike parts shortages, chip shortages, shipping shortages, and forces of nature simultaneously throughout development.

The resulting product and its manufacturing approaches are primed for navigating such challenges with agility, and competitive in-house solutions.

Performance. Fully Loaded.

Technical Specifications

Frame
6061 aluminum
Front hub
135mm 36h
Seat post
28.6mm
Fork
Rst guide w/75mm travel, lockout and preload
Front axle
5mm qr
Seat post clamp
Qr
Headset
Threadless 1-1/2 1-1/8 tapered
Rear hub
190mm 36h
Motor
Biktrix coaxial mid-drive motor
Shifter rear
Shimano alivio trigger shifter
Rear axle
Bolt-on
Battery sizes
Total capacity of 52v 38.5ah 2002wh:
52v 17.5ah 910wh (internal battery) +
52v 21ah 1092 wh (external range extender battery)
Rear derailleur
Shimano alivio 9 speed
Rims
26" black w/ round cutouts, 27.5" solid black
Display
Ds103
Cassette
11-34t 9 speed
Tire sizes
Chaoyang 26x4, chaoyang 27.5x3
Lights
Armageddon headlight
Chain
Kmc e9s - 124 links
Handlebar
700mm wide, 50mm rise w/31.8mm clamp
Assist type
Cadence + torque
Crank set
40t chainring w/152mm arms
Stem
Adjustable stem w/31.8mm clamp
Assist levels
0-5
Bottom bracket
High strength stainless steel square tapered
Grips
Mtb grips
Throttle
Low profile right-hand twist throttle / thumb throttle
Brakes
Iiipro e500 quad piston brakes w/203mm front, 220mm rear rotor
Saddle
Wide spring supported comfort saddle
Other
Rear rack, kickstand, front and rear fenders
Brake levers
Adjustable w/ integrated brake cutoffs
Frame
6061 aluminum
Front hub
135mm 36h
Seat post
28.6mm
Fork
Rst guide w/75mm travel, lockout and preload
Front axle
5mm qr
Seat post clamp
Qr
Headset
Threadless 1-1/2 1-1/8 tapered
Rear hub
190mm 36h
Motor
Biktrix coaxial mid-drive motor
Shifter rear
Shimano alivio trigger shifter
Rear axle
Bolt-on
Battery sizes
Total capacity of 52v 38.5ah 2002wh:
52v 17.5ah 910wh (internal battery) +
52v 21ah 1092 wh (external range extender battery)
Rear derailleur
Shimano alivio 9 speed
Rims
26" black w/ round cutouts, 27.5" solid black
Display
Ds103
Cassette
11-34t 9 speed
Tire sizes
Chaoyang 26x4, chaoyang 27.5x3
Lights
Armageddon headlight
Chain
Kmc e9s - 124 links
Handlebar
700mm wide, 50mm rise w/31.8mm clamp
Assist type
Cadence + torque
Crank set
40t chainring w/152mm arms
Stem
Adjustable stem w/31.8mm clamp
Assist levels
0-5
Bottom bracket
High strength stainless steel square tapered
Grips
Mtb grips
Throttle
Low profile right-hand twist throttle / thumb throttle
Brakes
Iiipro e500 quad piston brakes w/203mm front, 220mm rear rotor
Saddle
Wide spring supported comfort saddle
Other
Rear rack, kickstand, front and rear fenders
Brake levers
Adjustable w/ integrated brake cutoffs
Frame
6061 aluminum
Front hub
135mm 36h
Seat post
28.6mm
Fork
Rst guide w/75mm travel, lockout and preload
Front axle
5mm qr
Seat post clamp
Qr
Headset
Threadless 1-1/2 1-1/8 tapered
Rear hub
190mm 36h
Motor
Biktrix coaxial mid-drive motor
Shifter rear
Shimano alivio trigger shifter
Rear axle
Bolt-on
Battery sizes
Total capacity of 52v 38.5ah 2002wh:
52v 17.5ah 910wh (internal battery) +
52v 21ah 1092 wh (external range extender battery)
Rear derailleur
Shimano alivio 9 speed
Rims
26" black w/ round cutouts, 27.5" solid black
Display
Ds103
Cassette
11-34t 9 speed
Tire sizes
Chaoyang 26x4, chaoyang 27.5x3
Lights
Armageddon headlight
Chain
Kmc e9s - 124 links
Handlebar
700mm wide, 50mm rise w/31.8mm clamp
Assist type
Cadence + torque
Crank set
40t chainring w/152mm arms
Stem
Adjustable stem w/31.8mm clamp
Assist levels
0-5
Bottom bracket
High strength stainless steel square tapered
Grips
Mtb grips
Throttle
Low profile right-hand twist throttle / thumb throttle
Brakes
Iiipro e500 quad piston brakes w/203mm front, 220mm rear rotor
Saddle
Wide spring supported comfort saddle
Other
Rear rack, kickstand, front and rear fenders
Brake levers
Adjustable w/ integrated brake cutoffs

Size & Fittings

1
Effective Top Tube Length
530mm 20.9in
2
Seat Tube Length (Classic Bike Size)
460mm 18.1in
3
Reach
560mm 22in
4
Stack
520mm 20.5in
5
Chainstay Length
520mm 20.5in
6
Standover Height
450mm 17.7in
7
Head Angle
68° -
8
Seat Angle
71° -
9
Head Tube Length
180 mm 7.1 in
10
Fork Length
530mm 20.9in
11
Front Center
730mm 28.7in
12
BB (Bottom Bracket) Drop
50mm 2in
13
Fork Offset
30mm 1.2in
14
Wheelbase
1240mm 48.8in
15
Total Length
2000mm 78.7in
16
Max Seat Height
1000mm 39.4in
17
Min Seat Height
880mm 34.6in
18
Handlebar Height
1160mm 45.7in
19
Weight (Without Battery)
34kg 75lb
1
Effective Top Tube Length
560mm 22in
2
Seat Tube Length (Classic Bike Size)
420mm 16.5in
3
Reach
520mm 20.5in
4
Stack
500mm 19.7in
5
Chainstay Length
480mm 18.9in
6
Standover Height
430mm 16.9in
7
Head Angle
68° -
8
Seat Angle
71° -
9
Head Tube Length
180 mm 7.1 in
10
Fork Length
530mm 20.9in
11
Front Center
710mm 28in
12
BB (Bottom Bracket) Drop
40mm 1.6in
13
Fork Offset
30mm 1.2in
14
Wheelbase
1240mm 48.8in
15
Total Length
2000mm 78.7in
16
Max Seat Height
1000mm 39.4in
17
Min Seat Height
830mm 32.7in
18
Handlebar Height
1100mm 43.3in
19
Weight (Without Battery)
33.5kg 73.9lb

Need A Hand?

Chat With Us
We are always excited to hear from you. Just click the button below to activate chat now.
Chat Now
Book A Virtual Demo
Our eBike specialists can help you find your dream eBike and answer any questions you may have.
Book An Appointment Now
Give Us A Ring
24/7 e-mail support. 8/5 phone and live chat with eBike Specialists to help you in anyway.
+1-866-BIKTRIX

Customer Reviews

Based on 23 reviews
87%
(20)
4%
(1)
9%
(2)
0%
(0)
0%
(0)
K
Kenneth Shaw
Order delivered but I am still away

Hi, I was advised by family that order had arrived, however I am away from home currently, so it remains boxed and waiting in my garage for my return next month. Can’t wait !

J
Joshua McMinn
Awesome bike, but a little cheap on the overall package

So let's get this out up front. As an e-bike, this thing is AWESOME. It rides great. The motor is very springy and accelerates or climbs like a dream. It easily does 30mph on flat ground and can get to 35mph before you get to the point where the motor is going full blast to barely increase the speed, which is fine -- it's geared for quick acceleration and for use as a bicycle. If I wanted to go faster than 35mph, I would have bought a Sur Ron or something like that at a pretty similar price point. All and all, if you are looking for an electric bicycle that sits in the grey area between a bike and motorcycle, but is closer to the bicycle side of the spectrum, this is it. The suspension is smooth -- at least on pavement. The 27.5x3 Kendra tires I got are solid and a good compromise between super fat tires and "bike" tires. The metal fenders are built like tanks. While it would have been nice if it already supported it, the add on mount for a second battery is already there for when they get that working, which is nice. Basically no complaints on the actual ride.

So why not 5 stars? Because the overall package is a bit chintzy on quality of life features, and this is a premium price point. You could seriously start looking at electric motorcycles at this general price point, so that is the sort of thing this is competing against. The most glaring omission is that the bike ships with a rear reflector as opposed to a tail light that powers off the bike battery. Yes, this is officially an off road bike that is technically not street legal in most localities. Yes, the premium is mostly for the dual drive motor. But on the other hand, it was sold with a "commuter package", so "wink wink", we both know what is up, and for $5600 it ought to have a working tail light like most much cheaper e-bikes do. Yes, I can get a rechargeable battery powered tail light. But now I have to remember to take it off to charge it, remember to put it back on, and remember to turn it on separate from the headlight, and for the price of this bike I shouldn't have to do that.

Second, the included DS104 display that comes on it is a little underwhelming at this price point. It's mostly functional -- other than the fact that the software doesn't compensate for draw current when displaying battery remaining, causing the meter to swing wildly, and show much lower remaining batterly when the motor is running than what is true, it does the job (not sure if the battery gauge issue is Biktrix programming or the default display firmware). It's just that the plain black on white LCD feels very basic on what is a very premium bike. I'd probably forgive the look if the battery gauge properly corrected for draw current and didn't spazz out, but -- it kind of feels like they had trouble getting any display working with this motor, and managed to get this specific one barely functioning and just went with it, which is fine on a prototype. Less so on a sold premium product such as this.

To be fair, the included Armageddon headlight is definitely premium and not "chintzy", and I have no real complaints at all about it. A minor quibble that they had to hard wire splice it to the battery cable, apparently because they don't have it with a compatible slip plug, but then again, you won't be looking to replace this. The commuter package included rear rack is adequate -- I have no complaints about it other than the lack of places to bolt something onto it, but that complaint applies to literally *every* third rack on the market, so can't fault Biktrix for that.

Anyway, I do really love the bike part of the bike. The thing is a beast. It's incredibly fun to ride. It is quite amusing to beat cars off the line at traffic lights. (grins). It's just that for the price point, the overall package matters, and there are some quality of life misses here.

T
Timothy Hanson
Muscle Car of E-Bikes - Juggernaut XD Duo

I am impressed with my e-bike.
It is powerful, with power to spare.
I'm a big guy, but my new e-bike doesn't seem to notice.
The 11-speed gears when peddling shift smoothly, quietly and don't ever sound like the chain is going to jump to an adjoining sprocket. The brakes work well when needed. And the suspension gives me a comfortable low-shock ride over bumps.
Did I mention the power? I used to have a bagger motorcycle that would launch with a quick jersey on the throttle...this e-bike is no different. While riding I just feather the throttle and it responds. On my first tune-up ride I was peddling along on a slight downhill at about 15 mph. I gave a quick jerk to the throttle and the front wheel came off the ground. So, now I gently rotate the throttle when needed, and I rarely use more than 10 percent power.
I am very happy that I did the research to find a bike that can get me anywhere without getting off and walking, because I just can't peddle up the steep hills like when I was a young man.
I think I made the right choice of e-bike, and the concern about adequate power is no longer a concern.
If you want power, you'll get it with this e-bike. I would recommend this e-bike to anyone.

l
lon needles
XD bike

Seems fine.

S
Sam I am
Solid Bike but lacks

The bike is solid but distance per charge sucks and top speed is mediocre.
