Swift SO

Name: Swift Step-Over
Brand: swift-step-over-detail
SKU: SFT-SO-RD
Availability: OutOfStock
Rating: 4.57 (75 reviews)

4.5

CA$0 CA$2,599

Technical Specifications

Frame 6061 aluminum with fenders	Front hub Modus 100mm	Seat post Aluminum 30.4mm
Fork Mozo suspension fork	Front axle 5mm qr	Seat post clamp 36.2mm qr
Headset Threadless 1-1/8 straight	Rear hub Hub motor	Motor 500w rear hub
Shifter rear Shimano trigger 7 speed	Rear axle Bolt on	Battery sizes 48v17.5ah, 48v21ah, 52v17.5ah
Rear derailleur Shimano acera	Rims Black 40mm 36h	Display 500s
Cassette Shimano 14-28t	Tire sizes 27.5x2.15"	Lights Integrated head light + integrated tail light
Chain Kmc z7	Handlebar 31.8mm clamp	Assist type Torque, cadence
Crank set 178mm crank arms with 44t chainring	Stem Zoom clamp on	Assist levels 0-5 (0-3, 0-9)
Bottom bracket 73mm square taper w/torque sensor	Grips Leather slide on	Throttle Thumb throttle
Brakes Tektro md-m280 mechanical brake	Saddle Selle royal nebula	Other Bell integrated into left brake
Brake levers Tektro cl530

Frame 6061 aluminum with fenders	Front hub Modus 100mm
Seat post Aluminum 30.4mm	Fork Mozo suspension fork
Front axle 5mm qr	Seat post clamp 36.2mm qr
Headset Threadless 1-1/8 straight	Rear hub Hub motor
Motor 500w rear hub	Shifter rear Shimano trigger 7 speed
Rear axle Bolt on	Battery sizes 48v17.5ah, 48v21ah, 52v17.5ah
Rear derailleur Shimano acera	Rims Black 40mm 36h
Display 500s	Cassette Shimano 14-28t
Tire sizes 27.5x2.15"	Lights Integrated head light + integrated tail light
Chain Kmc z7	Handlebar 31.8mm clamp
Assist type Torque, cadence	Crank set 178mm crank arms with 44t chainring
Stem Zoom clamp on	Assist levels 0-5 (0-3, 0-9)
Bottom bracket 73mm square taper w/torque sensor	Grips Leather slide on
Throttle Thumb throttle	Brakes Tektro md-m280 mechanical brake
Saddle Selle royal nebula	Other Bell integrated into left brake
Brake levers Tektro cl530

Frame

6061 aluminum with fenders

Front hub

Modus 100mm

Seat post

Aluminum 30.4mm

Fork

Mozo suspension fork

Front axle

5mm qr

Seat post clamp

36.2mm qr

Headset

Threadless 1-1/8 straight

Rear hub

Hub motor

Motor

500w rear hub

Shifter rear

Shimano trigger 7 speed

Rear axle

Bolt on

Battery sizes

48v17.5ah, 48v21ah, 52v17.5ah

Rear derailleur

Shimano acera

Rims

Black 40mm 36h

Display

500s

Cassette

Shimano 14-28t

Tire sizes

27.5x2.15"

Lights

Integrated head light + integrated tail light

Chain

Kmc z7

Handlebar

31.8mm clamp

Assist type

Torque, cadence

Crank set

178mm crank arms with 44t chainring

Stem

Zoom clamp on

Assist levels

0-5 (0-3, 0-9)

Bottom bracket

73mm square taper w/torque sensor

Grips

Leather slide on

Throttle

Thumb throttle

Brakes

Tektro md-m280 mechanical brake

Saddle

Selle royal nebula

Other

Bell integrated into left brake

Brake levers

Tektro cl530

Size & Fittings

1	Effective Top Tube Length	585mm	23in
2	Seat Tube Length (Classic Bike Size)	455mm	17.9in
3	Reach	480mm	18.9in
4	Stack	675mm	26.6in
5	Chainstay Length	470mm	18.5in
6	Standover Height	730mm	28.7in
7	Head Angle	75°	-
8	Seat Angle	75°	-
9	Head Tube Length	140 mm	5.5 in
10	Fork Length	460mm	18.1in
11	Front Center	700mm	27.6in
12	BB (Bottom Bracket) Drop	30mm	1.2in
13	Fork Offset	20mm	0.8in
14	Wheelbase	1150mm	45.3in
15	Total Length	1840mm	72.4in
16	Max Seat Height	1005mm	39.6in
17	Min Seat Height	850mm	33.5in
18	Handlebar Height	1060mm	41.7in
19	Weight (Without Battery)	23.6kg	52lb

FAQ & Guides

Guide Spare Parts Finder

Need A Hand?

Chat With Us

We are always excited to hear from you. Just click the button below to activate chat now.

Chat Now

Book A Virtual Demo

Our eBike specialists can help you find your dream eBike and answer any questions you may have.

Book An Appointment Now

Give Us A Ring

24/7 e-mail support. 8/5 phone and live chat with eBike Specialists to help you in anyway.

+1-866-BIKTRIX

Nice bike that could be even better

Buying the bikes was not as straight forward as I expected, their website had some glitches that prevented me to take advantage of their promotions, however an email to their support team fixed that.
After receiving my bikes I found out that some parts in both of the handle bars were assembled in the wrong order so with some help from their support team I was able to fix the issue and get some spare parts that were damaged in the process.
All in all, I like these bikes very much, they have all the basics at a good price. However, they could be even better if you could upgrade some things like a headlamp connected to the ebike controls and battery, your only option is a to get rechargeable headlamp or one with external batteries.
Their support team is great.

Poor quality when picked up, wobbly front and back tires

As other have mentioned, very poor quality control. Picked up a Swift X on Saturday from the main branch in Saskatoon. Took it for the first ride to my office (11km away) and noticed both front and back wheels have a wobble. Walked over and spoke with them about fixing it, but needs the bike for a full day. Should they not check the bike over properly before picking it up?

Poor quality control

Like other reviews have said. Good looking bike but poor quality control. Front wheel wobble out of the box. Issue with torque sensor, bike sometimes has weak pedal assist. Support wants me to take a video to show the issue but how can I show the weaker feedback in video. Feels dangerous to be requested to ride a bike and take a video.

My Swift X - overall a mediocre bicycle

Good
Pleasing profile, 29 inch wheels yes, critical to have a throttle - is the only feature that makes the bike ridable
Poor
The torque and cadence sensors work poorly - lack sensitivity
Factory blocking of the LCD exacerbates the problem
Bad
one of the bolts for the front caliper was cross threaded and left, the other was only finger tight
obviously no real quality control, as I found the problem not Biktrix
Conclusion
Nice apprearance, but poor workmanship and almost worthless electronic controls

Assembled yesterday. Ride tested. So far so good.
